High Flexibility SS wire mesh Belt , dutch Weave Wire Mesh Width 1m
- 1.6m
Product description of ss wire mesh belt
The type of net is called the mat type network because his latitude
and longitude wire diameter is different and the number of meshes
is different . Reasonably match the silk and mesh to achieve the
filtration density that can not be achieved by the square mesh .
Therefore , the mat type net is a fine-grained dense mesh , but
generally the warp diameter is larger than the weft diameter . The
contrast weave is called contrast because the weft is much thicker
than the warp .
Product Application of ss wire mesh belt
It is used in precision pressure filters , fuel filters and vacuum
filters for aerospace , petroleum , chemical , chemical fiber ,
rubber , tire manufacturing , metallurgy , medicine , food and
other industries .
Product Feature of ss wire mesh belt
The mat network has many advantages in the control of ink flow .
The same size of the mat type mesh is better for better control of
ink precipitation , and it will also effectively avoid dot gain in
the printing process , because even at the dot coverage rate . In
higher areas, the overprinting rate of such outlets is still much
lower than other outlets .
Another advantage of mat-type dots in screen printing is that all
the dots are arranged next to each other instead of being stacked
on top of each other as in the traditional mesh type . The
reduction in stacking dots means that the lack of ink caused by the
pressure at the top of the dots during the printing process is also
alleviated .
Product parameters of ss wire mesh belt
plain weave Dutch mesh |
Number | Mesh(warpxweft) | Wire diameter (warpxweft) | Aperture (um) | Weight (kg/m2) |
32# | 8 x 62 | 0.63mm x 0.45mm | 300 | 5.42 |
40# | 10 x 79 | 0.50mm x 0.355mm | 250 | 3.16 |
48# | 12 x 64 | 0.58mm x 0.40mm | 280 | 2.9 |
55# | 14 x 88 | 0.40mm x 0.30mm | 180 | 2.54 |
76# | 19 x 140 | 0.315mm x 0.20mm | 140 | 1.88 |
80# | 20 x 300 | 0.35mm x 0.20mm | - | 3.6 |
95# | 24 x 110 | 0.355mm x 0.25mm | 120 | 2.45 |
100# | 25 x 140 | 0.28mm x 0.20mm | 100 | 1.95 |
120# | 30 x 150 | 0.25mm x 0.18mm | 80 | 1.68 |
140# | 35 x 175 | 0.224mm x 0.16mm | 71 | 1.52 |
160# | 40 x 200 | 0.20mm x 0.14mm | 60 | 1.40 |
180# | 45 x 250 | 0.16mm x 0.112mm | 56 | 1.09 |
200# | 50 x 250 | 0.14mm x 0.11mm | 53 | 1.04 |
220# | 55.5 x 280 | 0.14mm x 0.10mm | 50 | 0.92 |
240# | 65 x 330 | 0.11mm x 0.08mm | 36 | 0.71 |
280#(1) | 70 x 350 | 0.11mm x 0.08mm | 35 | 0.72 |
280#(2) | 70 x 385 | 0.11mm x 0.07mm | 32 | 0.75 |
300# | 78 x 700 | 0.11mm x 0.08mm | 30 | 1.39 |
315#(1) | 80 x 400 | 0.10mm x 0.065mm | 40 | 0.62 |
315#(2) | 80 x 600 | 0.10mm x 0.06mm | - | 0.74 |
315#(3) | 80 x 800 | 0.15mm x 0.04mm | - | 0.77 |
320# | 81 x 780 | 0.10mm x 0.07mm | 30 | 1.22 |
354# | 90 x 550 | 0.12mm x 0.05 | - | 0.667 |
Width:1m-1.6m |
