Plain Flat And Uniform Opening Polyester Forming Mesh Belt For
Corrugated Paper
Product Description:
Polyester Forming Mesh Belt
It's endless flat polyester forming fabric and edges are heat-cut
and sealed
It has wide uage in paper mill to produce various kinds of papers
Polyester forming fabrics can be divided into
4-shed,5-shed,7-shed,8-shed,16-shed and 24-shed
according to the weaving pattems.It can be divided into single
layer fabric,double layer fabric,double layer fabric
two and half layer faabric and three layer fabric.according to the
difference of fabric layers.We will choose the
suitable forming wire for your paper machine according to your
paper machine detail information
The polyester forming fabrics is an important piece of equipment on
a papermaking machine and is a device for
forming and dewatering paper sheets on a papermaking machine, it
dewaters the pulp suspension from the headbox
then transports the paper web
Features:
To avoid the blemish on the paper sheet the most important
requirement of monofilament
is uniformity diameter over the entire length of the yarn
High tenacity polyester (PET) monofilament yarns are used in the
warp (MD) to provide
the required high tension of the forming fabrics, and the diameter
of MD yarn usually
between 0.12 to 0.30 mm
The monofilament yarn in the weft (CD) of the paper side is usually
100% polyester in
high density to get better fiber support while the mechanical
(bottom) layer is composed
of 50% polyester and 50% nylon in thicker diameter to ensure better
wear resistance property
Nylon monofilament provides good abrasion resistance but it’s not
stable in hydrolyzed
as PET under humidity conditions, so it will not exceed 50%
typically
The diameter of the weft (CD) yarn is usually between 0.11 and 0.45
mm
Technical Parameters:
| Product Name | Polyester Forming Screen |
|---|
| Polyester forming mesh | 100% Polyester |
| Polyester filter belt | Smooth And Flat |
| Polyester filter belt for paper machine | High Strength |
| Air permeability | 4000-8000 M3/m2h |
| CFM | 900-1500 |
| Material | 100% Polyester |
| Temperature resistance | 200 ℃ |
| Tensile Strength | High Strength |
| Surface | Smooth And Flat |
| Thickness | 0.4-0.9mm |
| Sample | Available |
| Weight | 0.3-2.5 KG/M2 |
Product Features
1. Long service life, wear resistance, the net loss is low
2. High fatigue resistance, acid, weak alkali resistance
3. The mesh mark light, forming quality is good
4. Light weight, easy to transport, set net easy operation
Product Advantages
- High-quality material ensures the stability and durability of the
product.
- Smooth and flat surface prevents paper damage during the drying
process.
- Efficient filtration and drying capabilities improve the production
efficiency of papermaking.
- Adjustable loop width makes it suitable for different types of
papermaking machines.
- Autogenous ring steel card interface ensures the stability and
durability of the product.
- Available in blue and white colors for easy identification and
replacement.
Packaging and Delivery
The Polyester forming mesh is packaged in wood to ensure the safety
of the product during transportation
The delivery time is based on the order quantity, and the product
can be delivered within 7-15 days
The minimum order quantity is 1 piece, and the supply ability is
10000 pieces per month
The Polyester forming mesh, also known as Polyester filter belt, is
a high-quality and durable product that is widely
used in the paper industry for its excellent filtration and drying
capabilities. It is suitable for various types of papermaking
machines and is available in different sizes and colors. With the
joint of autogenous ring steel card interface
the product ensures stability and durability, making it an
essential and reliable tool for packaging paper manufacturing
Choose Hebei Reking, choose high-quality and efficient Polyester
Dryer Screen for your papermaking needs
Packing and Shipping:
Packaging and Shipping of Polyester Dryer Screen
Our Polyester Dryer Screen is carefully packaged to ensure safe and
secure delivery to our customers.
Each roll is wrapped in plastic and then placed in a sturdy
cardboard box. The box is then sealed with strong
tape to prevent any damage during transit
We offer both sea and air shipping options for our customers. For
sea shipping, our products are loaded onto
pallets and secured with straps to prevent shifting during
transportation. For air shipping, our products are
carefully packed and placed in sturdy boxes to ensure safe delivery
We work closely with reliable shipping companies to ensure timely
delivery of our products to our customers
We also provide tracking information so our customers can keep
track of their order during transit
Our Polyester Dryer Screen is shipped worldwide, with options for
express shipping for urgent orders
We strive to provide the best packaging and shipping services to
ensure our customers receive their products
in perfect condition and on time
